Bridge board technology

SunRise LED bridge board technology makes connection quick and easy without cables, improving the stability and durability of the LCM screen.

Quick assembly

Simply put the pin into the hole. The panels are assembled together and the pins make the connection firm and safe.


USMade SOUTHCO fasteners enable easy adjustment between the adjacent panels.

Hanging beam

New smart mechanical design ensures a seamless connection of the whole screen.(Max. cascade rows:13 rows.

Test button

The test button helps you assure connectivity

Panel IP rating

IP65 protection level ensures the LCM screen will work well in harsh weather conditions.

Convenient Handle on back

Two plastic handles on the back of each panel enable convenient handling and adjustments.Present your advertising with maximum impact. Stream live video, photos and communications in up to 4 billion colors.Programming is accomplished quickly and easily using LC Net, our innovative and powerful software.LC Net software has network capabilities allowing connection to multiple displays running the same message or different messages simultaneously.

Product SeriesPixel Pitch (mm)Indoor / OutdoorCabinet Size (mm)Brightness (Nits)Refresh Rate (Hz)
LCM66mIndoor768x7681200360 /1200
LED Type:3-in-1 SMD 5050 with bigger chips and higher thickness.
Display Capabilities: Multiple controller options will allow the Live Video displays to display many content types. Text, time, temperature, database information, full-color graphics, and VGA or DVI broadcasts.
IC Type:MBI 5042 with high refresh frequency.
Excellent Construction Aluminum, slim, lightweight and easy to assemble.
Viewing Angle:140 degree horizontal and 140 degree vertical provides a very wide viewing angle.
Database DisplayTable Line-InNetwork FunctionBackground PlayText File Support (Word, Excel)Adding Background MusicCalendar (Displays Transparent)Date, Time & Temperature (Positive – Negative timing functions)Play ScheduleMultimedia File Support (MPG, MPEG, MPV, MPA, AVI, VCD, SWF, RM, RA, RMJ, ASF)Video Source Chroma, Saturation, Brightness, Contrast software regulationPlaying Multi-Task Automatically
Multi-display Synchronism Function Multiple displays can not only play different content independently, but LC Netalso the same content. Multiple displayscan be combined to play large content. Both software and hardware support video play. LC Net Software Supporting multi-display: multi-display edits separately database display; table line-in; network function; background play; playing schedule multi-window and multi-task display synchronously; text supports Word,Excel; adding background music to program window; supporting all the cartoon documents(MPG /MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RMJ/ASF...); abundant picture browse types; date、time、date+time 、analog clock etc, all kinds of positive-negative timing functions; calendar displays transparently; playing multi-task automatically ; supporting external program interface; video source chroma、 saturation、brightness、contrast software regulation.
Pixel Composition1 Red, 1 Pure Green, 1 Blue SMD
Display Color Full Color (4.4 Trillions)
Cabinte size768mmx768mm / 30.25"x30.25"
Cabinte Depth5.7" (145mm) Including handels
Viewing Angle140° Horizontal / 140° Vertical
SpecificationSMD 3in 1
Weight of each Cabinteabout 39.7 LB / 18KG
Available SignalsDVI, S-Video, RGB, VGA and etc.
Accepted FilesText, Animation, Picture, Database, Video and etc. Video Prosessor Available
Operating Temperature-40°F ~ 149°F (-40°C ~ 65°C)
Operating Humidity10% ~ 90%
Water ProofingFront: IP65

1 Year Free Parts/In-house Labor Warranty with Optional Extended Warranty Plan

For 10+ years, we have been supporting our products around the world. With more than 100 dealers in the US and around the globe, your SunRise LED Display is well covered. Should a hardware failure occur, your LCM Display is covered by a 1-Year factory protection plan for parts and 1-Year factory Labor protection plan at no extra charge. The SunRise Extended Service Plan is also available for an additional cost to provide the next level of investment protection. If you experience a hardware failure with a covered product during the plan's term, simply call the toll-free number, report the issue, and after basic troubleshooting, if the issue cannot be resolved over the phone, you will be given instruction for the next steps to making the necessary repairs.
