Versa Curve

Indoor
LED Curve Tile System
Create your own Curve!

Light Weight
Easy Installation
Saving on Shipping
Front and Rear Maintenance

Realize Your Unlimited Creativity

SunRise LED’s VersaCurve  display is particularly suited to creative indoor applications. The SunRise LED boasts a fully articulated panel design which can be used in convex, concave and curvilinear applications. The high contrast ratio, superior colour fidelity and mechanical accuracy of the SunRise LED range combine impeccably to form the ultimate curve able high resolution indoor LED display. SunRise LED is used extensively in the indoor retail, broadcast, and entertainment industries and is available in a variety of pixel pitch options to suit all applications. SunRise LED may be used for fixed or rental applications

ModelVersaCurve-2XVersaCurve-3XVersaCurve-3VersaCurve-6VersaCurve-10
Physical Pitch2.9 mm3.2mm3.9mm6.9mm10.4mm
Pixel ConfigurationSMDSMDSMDSMDSMD
Pixel Density112,896 pixels/m² 28,224 pixels/panel97,344 pixels/m² 24,336 pixels/panel65,536 pixels/m² 16384 pixels/panel20,736 pixels/m² 5,184 pixels/panel9,216 pixels/m² 2,304 pixels/panel
Module Dimensions (mm)500*125500*125500*12540.5*500/82*50040.5*500/82*500
Panel Dimensions (mm)500*500*70500*500*70500*500*70500*500*63.5500*500*63.5
Modules Per Panel(W x H)1 X 41 X 41 X 42 x 1/5 x 12 x 1/5 x 1
Physical Resolution of Module(W x H)168 * 42156 * 39128 * 326 * 72/12 * 724 * 48/8 * 48
Physical Resolution of Panel(W x H)168 X 168156 * 156128 * 12872 * 7248 * 48
Weight Per Panel8.5 kg/panel8.3 kg/panel8.1 kg/panel8.5 kg/panel8.5 kg/panel
Weight Per m²34 kg/m²33.2 kg/m²32.4 kg/m²34 kg/m²34 kg/m²
Processing16 Bit16 Bit16 Bit16 Bit16 Bit
Colours281 Trillion281 Trillion281 Trillion281 Trillion281 Trillion
Contrast Ratio4000 : 14000 : 14000 : 13000 : 13000 : 1
Average Power Consumption36 – 60 w/panel49 – 70 w/panel49 – 70 w/panel32 – 47.5 w/panel32 – 47.5 w/panel
Max Power Consumption140 w/panel140 w/panel140 w/panel95 w/panel95 w/panel
Operating Temperature / Humidity-10~40℃ / 10%~60%-10~40℃ / 10%~60%-10~40℃ / 10%~60%-10~40℃ / 10%~60%-10~40℃ / 10%~60%
Storage Temperature / Humidity-30~60℃ / 10%~60%-30~60℃ / 10%~60%-30~60℃ / 10%~60%-30~60℃ / 10%~60%-30~60℃ / 10%~60%
Brightness1200 nits1200 nits1200 nits1500 nits1500 nits
Refresh Rate1920 – 3840 Hz1920 – 3840 Hz1920 – 3840 Hz1920 – 3840 Hz1920 – 3840 Hz
Horizontal Viewing Angle140°140°140°140°140°
Vertical Viewing Angle120°140°140°120°120°
Expected Lifetime100,000 Hrs100,000 Hrs100,000 Hrs100,000 Hrs100,000 Hrs
Max Stacking20 panels20 panels20 panels20 panels20 panels
Max Hanging16 panels16 panels16 panels16 panels16 panels
ServicingFront and BackFront and BackFront and BackFront and BackFront and Back
IP RatingIP43IP43IP43IP43IP43
CertificationCE, RoHS, EMC Class ACE, RoHS, EMC Class ACE, RoHS, EMC Class ACE, RoHS, EMC Class ACE, RoHS, EMC Class A

Oman

Project: Government of Oman

Product model:VersaCurve

Year:2015

2 Year Free Parts/Factory Labor Warranty

For 15+ years, we have been supporting our products around the world. With more than 100 dealers in the US and around the globe, your SunRise LED Display is well covered.

If you experience a hardware failure with a covered product during the plan’s term, simply contact your distributor to report the problem. If the issue cannot be resolved over the phone with your distributor, you will be given instruction for the next steps for making the necessary repairs.

Versa Tile Curve!

Create your own design.

Front Serviceable

Any module within the display can be removed from the front in seconds with very little effort.

Fully articulated flexible panels

VersaCurve can form concave, convex and cylindrical shapes. Each panel can curve by 20°, convex or concave.

Fully articulated flexible panels

Horizontal curve, vertical curve and cylindrical possibilities

Dual backup system

Power supply, signal cable, control system, socket backup available
