Polara Linear Light Series

SunRise LED offers energy efficient LED lighting solutions for many applications.
Featuring an innovative design, ONE lamp can be used in SIX types of brackets:
canopy surface mount, canopy recessed mount, Wall Pack tilt, tunnel light type,
wall pack type, pendant mount type high/low bay. Available in 30 to 240watt
(30W/module, range from 1 to 10 modules) models in 4000 to 6000K correlated
color temperature (CCT), the Polara lights could be widely used in warehouse,
factory, workshop, gym, shop, gas station, parking garage, building, corporate
and school campuses and municipalities etc.

Bright-A Series Specification

Bright-B Series Specification

SunRise LED Polara Series LED Lighting

SunRise LED offers energy efficient LED lighting solutions for many applications. Featuring an innovative design, ONE lamp can be used in SIX types of brackets: canopy surface mount, canopy recessed mount, flood light tilt, tunnel light type, wall pack type, pendant mount type high/low bay. Available in 30 to 240 watt (30 W/module, range from 1 to 10 modules) models in 4,000 to 6,000 K correlated color temperature (CCT), the Polara lights could be widely used in warehouses, factories, workshops, gyms, shops, gas stations, parking garages, buildings, corporate and school campuses and municipalities etc. Our advanced modular design structure helps to realize power savings by reducing the module quantity in order to meet different lumen requirements for street lighting. These lights deliver up to 26,180 lumens to support main and ancillary streets, and are available in different IES beam distribution types for different projects.

3 Year Free Parts/Factory Labor Warranty With Optional Extended Warranty Plan

For 10+ years, we have been supporting our products around the world. With more than 100 dealers in the U.S. and around the globe, your SunRise LED display is well covered. If you experience a hardware failure with a covered product during the plan’s term, simply call your distributor, report the issue, and if after basic troubleshooting the issue cannot be resolved over the phone, you will be given instructions for the next steps to making the necessary repairs.

SunRise LED Polara Series Features:

• Replaceable and upgradeable modular design.
• Durable, die-cast aluminum housing
• Easy assembly, easy installation, and tool-free maintenance.
• Advanced modular structure design for excellent heat dissipation performance
• Universal (120 to 277) volt operation with no re-strike delay; 347-480volt models available by custom order
• High luminance uniformity with accurate light
• Advance light Distribution technology
• One lamp, six bracket types, could be used in many occasions.
• IP65 rating
• Dimmable

Construction

The modular die cast frame secures a thermally conductive extruded aluminum alloy heat sink to an independent electrical chamber. The revolutionary design allows for passive cooling and natural self-cleaning ensuring our LED street lights offer superior heat dissipation and eliminating any issues with dust or moisture.

Optics

The Polara Series LED light offers different optics manufactured from injection molded acrylic. Optics realize consistent distribution with the scalability to meet customized application requirements.

Electrical

• Input Voltage: UNIV 100V – 277V
• Optional 347V-480V
• Power Factor: 95%
• Frequency Range: 50/60Hz
• Driver Current: 700Am
• Surge Protection: 4-10Kv

Physical Performance

• LED Type: CREE XP-G/Philips Lumiled
• LED driver: Philips ADVANCED LED driver
• LED Lifetime: >50,000 hours
• Color Temperature: 4000K – 6000K
• Color Rendering Index: >70

Housing color

Cold grey, matt white or matt black.

Mounting

• Surface Mount
• Pendant Mount
• Recessed Mount
• Wall Mount

Other

• IP Rating: 65
• Operating Temperature: -40° to 55°C
• Operating Humidity: 10-95%

Certification

• IES Data Available – LM79 & LM80 National Listed Lab
• Tests In Accordance with IES Standards.
• UL, cUL, CE, CB, RoHS, DLC

Available Models
